Viltrox DC-X Series Touchscreen 6 Inch FHD Camera Monitor

Ultra-Bright Display: 2000 Nits brightness ensures clear visibility in strong light.

Full HD IPS Screen: 6-inch FHD 1080P IPS display offers true-to-life colors and wide viewing angles.

Peak Focus Accuracy: Capture key points with precision for sharp, high-quality images.

Comprehensive Monitoring Tools: Advanced tools like waveform and 3D LUT for precise control and real-time color grading.

Customizable User Experience: Intuitive touchscreen and programmable quick keys for efficient operation.

Versatile Connectivity and Durability: HDMI and SDI inputs/outputs for seamless integration with various devices; lightweight aluminum alloy body designed for reliability in all environments.

Specification

Screen:

6-inch IPS Touchscreen

Resolution:

1920x1080

Ratio:

16:9

Screen Contrast Ratio:

1000:1

Refresh Rate:

60Hz

Viewing Angle:

160°

Pixel Density:

360PPI

Screen Color Gamut:

100%±3% SRGB/Rec.709

Color Depth:

8 bit

Input Interface:

DC-X3: HDMI、SDI

DC-X2: HDMI

Output Interface :

DC-X3: HDMI、SDI

DC-X2: HDMI

Power Interface :

DC 12-18V/2A、Type-C>9V/3A

USB Interface :

Supports USB interface upgrade, 3DLut file import

Product Dimension :

DC-X3: 155.4x98.4x30mm

DC-X2: 155.4x98.4x26.8mm

Product Weight :

DC-X3 ≈ 350g

DC-X2 ≈ 324.5g

Audio Output:

3.5mm headphone jack

Battery :

Li-battery NP-F550/F570/F750/F770/F960/F970

Storage Temperature:

0℃~75℃

$238.00
$238.00
Model
Quantity

Free shipping

Money-Back Guarantee

Support 24/7

Easy Returns and Exchanges

DC-X Touch Screen 6'' Pro Monitor

Precision and Clarity for the Modern Filmmaker

vibrant colors& superior performance

  • Clear FHD 1080P Display
  • Vibrant IPS Display for True Color
  • 160° Ultra-Wide Viewing Angle
  • High Contrast, Rich Detail
  • Professional Color Gamut Coverage
  • Smooth Visuals with 60Hz Refresh Rate

user-friendly design

touchscreen for effortless control

 customizable shortcut keys

superior brightness for any environment

intelligent thermal management

efficient cooling system

Full aluminum body has multiple cooling designs, a built-in cooling fan, and an intelligent temperature control system that adjusts the fan speed based on the body temperature.

HD Monitoring

wide device compatibility

4k 30hz signal input and loop output

SDI Compatibility(DC-X3)

comprehensive monitoring tools

aluminum alloy compact body

  • Lightweight and Sturdy Design
  • Less than 350g Compact and Easy to Carry
  • Perfect for On-the-Go Shooting
  • Aluminum Alloy Excellence Shell

multiple power supply options

  • NP-F lithium batteries, DC 12-18V, and Type-C 9V/3A inputs
  • Extended Battery Life for Long Shoots
  • Stay powered up in studio, on location, or outdoors

quick-release sunhood

Features a detachable sunhood design for quick setup and storage. Effectively blocks light sources during outdoor shooting, ensuring optimal viewing and protecting the screen from scratches.



*Aluminum alloy cage sold separately.

DC-X2 & DC-X3 Product Diagram

dC-x3

1. Return/Menu Button

2. Shortcut Keys

3. Screen

4. Fan Exhaust Vent

5. Indicator Light

6. Power Button

7. HDMI Input

8. HDMI Output

9. Headphone Jack

10. Cooling Air Inlet
11. 1/4 Inch Screw Hole

12. Cooling Air Inlet

13. DC Jack

14. Type-C Port

15. Cooling Air Inlet

16. 1/4 Inch Screw Hole

17. Cooling Air Inlet

18. USB Port

19. Battery Release Button

20. Battery Compartment

21. SDI Input

22. SDI Output

dC-x2

1. Return/Menu Button

2. Shortcut Keys

3. Screen

4. Fan Exhaust Vent

5. Indicator Light

6. Power Button

7. HDMI Input

8. HDMI Output

9. Headphone Jack

10. Cooling Air Inlet

11. 1/4 Inch Screw Hole

12. Cooling Air Inlet

13. DC Jack

14. Type-C Port

15. Cooling Air Inlet

16. 1/4 Inch Screw Hole

17. Cooling Air Inlet

18. USB Port

19. Battery Release Button

20. Battery Compartment

in the box

  • DC-X2/DC-X3 monitor
  • Hard-shell carrying case
  • Custom ball head
  • NP-F550 battery
  • Quick-release sunhood
  • Custom screen protector
  • HDMl Cable
  • Mini HDMl cable
  • USB-C power cable
  • Manual/warranty card
  • Packaging
